Home > Stainless Steel Seamless Tube >

ASME SA213 TP316, TP316L, TP316H, TP316Ti, TP316LN, SUS316, SUS316L, Stainless Steel Seamless Tube For Boiler

Product Categories
Yuhong Group Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

ASME SA213 TP316, TP316L, TP316H, TP316Ti, TP316LN, SUS316, SUS316L, Stainless Steel Seamless Tube For Boiler

Brand Name : YUHONG

Model Number : TP316 , TP316L , TP316H, TP316Ti , TP316LN, 1.4404

Certification : ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008

Place of Origin : China

MOQ : 100KGS

Price : negotiable

Payment Terms : T/T, L/C

Supply Ability : 1500 tons per month

Delivery Time : 10days->

Packaging Details : Ply-wooden Case /Iron Case/ Bundle with plastic Cap

Standard : ASTM A213, ASME SA213 , EN 10216-5 , GOST 9941-81 , JIS G 3459

Certificate : ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008

Material Grade : TP316 , TP316L , TP316H, TP316Ti , TP316LN , SUS316, SUS316L , 1.4404

NDT : Eddy Current Test ( ASTM E426), Ultrasonic Test (ASTM E213 ), Hydrostatic Test ( ASTM A1016) , Penetration Test（ASTM E165）

Surface : Pickled , Bright Annealed, Polished

OD : 6.35mm, 7.92mm, 9.53mm, 12.7mm, 15.88mm , 19.05mm , 22.23mm, 25.4mm, 31.75mm , 38.1mm , 44.45mm , 50.8mm, 57.15mm , 63.5mm, 76.2mm, 88.9mm, 101.6mm

WT : 10 Bwg (3.4mm ), 12 Bwg (2.77mm), 13 Bwg (2.413mm), 14 Bwg (2.11mm), 16 Bwg (1.65mm) 18 Bwg (1.24mm) 20 Bwg(0.89mm)

Length : Max. : 32m/pc

Contact Now

ASME SA213 TP316L (1.4404) Stainless Steel Seamless Tube for boiler and heat exchange application

Yuhong Group supply Boiler tube , Heat Exchange Tube, Air Cooling Tube , Condenser Tube more than 32 years , and our material grade contain Stainless Steel , Duplex Steel , Super Duplex Steel , Hastelloy , Monel , Inconel , Incoloy , Cr-Mo alloy , Copper alloy steel , and very year sell more than 80000 tons pipes and tubes to our client projects. And up to now we already export more than 55 countries, Like Italy, UK, Gernmany, USA, Canada, Chile, Colombia, Saudi Arabia, Korea, Singapore, Austrial, Poland, France , .... The pipe and tube was width used in Mining, Energy, Petrochemical, Chemical Industry, Food plant, Paper plant, Gas and Fluid Industry etc.And our group branch company and factory have been already approved by :ABS, DNV, GL, BV, PED 97/23/EC, AD2000-WO, GOST9941-81, CCS, TS, CNNC, ISO9001-2008, ISO 14001-2004.

Stainless Steel Seamless Tube Testing:
  • 1>.DFARS compliant
  • 2>.EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)
  • 3>.100% Radiography Test Report---If welded type
  • 4>.Raw Materials Certificate
  • 5>.Third Party Inspection Report
  • 6>.Fumigation Certificates
  • 7>.Heat Treatment Charts
  • 8>.HS Code Commercial Invoice
  • 9>.Form A for Generalized System of Preferences (GSP)
  • 10>.Manufacturer Test Certificate
  • 11>.Moisture testing
  • 12>.Surface roughness measurement
  • 13>.Laboratory Test Certificate from Govt. Approved Lab
Stainless Steel Seamless Tube Application:
  • 1>.Common industrial services (Petroleum, chemical, paper, fertilizer, fabric, aviation and nuclear)
  • 2>.Fluid, gas and oil industry
  • 3>.Heat transmission and pressure service
  • 4>.Construction and ornamental
  • 5>.Boilers and Heat exchangers
  • 6>.Decoration purpose, boiler, auto parts, medical device, food industry, building materials)

Stainless Steel Seamless Tube Chemical Composition:

MATERIAL
 　 C MN SI P S CR MO NI N
SA213 TP 316L Tube Min - - - - - 16 2 10 -
Max 0.03 2 0.75 0.045 0.03 18 3 14 0.1
SA213 TP 316H Tube Min 0.04 0.04 0 - - 16 2 10 -
max 0.1 0.1 0.75 0.045 0.03 18 3 14 -

Stainless Steel Seamless Tube Mechanical Properties:

GRADE
 TENSILE STRESS YIELD STR ELONG HARDNESS
(MPA) MIN 0.2% PROOF (% IN 50MM) MIN
　 (MPA) MIN 　 ROCKWELL B (HR B) MAX BRINELL (HB) MAX
SS 316L Tube 485 170 40 95 217
SS 316H Tube 515 205 40 95 　

Stainless Steel Seamless Tube Pressure Rating:

OD inches
 Ave. Wall inches Min Yield Strength (PSI) Min Tensile Strength (PSI) Theoretical Burst Pressure * (PSI) Working Pressure (PSI) 25% of Burst Theoretical Yield Point ** (PSI) Collapse Pressure *** (PSI)
0.25 0.02 30,000 75,000 14,286 3,571 5,714 4,416
0.25 0.028 30,000 75,000 21,649 5,412 8,660 5,967
0.25 0.035 30,000 75,000 29,167 7,292 11,667 7,224
0.25 0.049 30,000 75,000 48,355 12,089 19,342 9,455
0.25 0.065 30,000 75,000 81,250 20,313 32,500 11,544
0.375 0.02 30,000 75,000 8,955 2,239 3,582 3,029
0.375 0.028 30,000 75,000 13,166 3,292 5,266 4,145
0.375 0.035 30,000 75,000 17,213 4,303 6,885 5,077
0.375 0.049 30,000 75,000 26,534 6,634 10,614 6,816
0.375 0.065 30,000 75,000 39,796 9,949 15,918 8,597
0.5 0.02 30,000 75,000 6,522 1,630 2,609 2,316L
0.5 0.028 30,000 75,000 9,459 2,365 3,784 3,172
0.5 0.035 30,000 75,000 12,209 3,052 4,884 3,906
0.5 0.049 30,000 75,000 18,284 4,571 7,313 5,316L
0.5 0.065 30,000 75,000 26,351 6,588 10,541 6,786
0.5 0.083 30,000 75,000 37,275 9,319 14,910 8,307
0.625 0.02 30,000 75,000 5,128 1,282 2,051 1,859
0.625 0.028 30,000 75,000 7,381 1,845 2,953 2,568
0.625 0.035 30,000 75,000 9,459 2,365 3,784 3,172
0.625 0.049 30,000 75,000 13,947 3,487 5,579 4,335
0.625 0.065 30,000 75,000 19,697 4,924 7,879 5,591
0.625 0.083 30,000 75,000 27,124 6,781 10,850 6,910
0.625 0.095 30,000 75,000 32,759 8,190 13,103 7,734
0.625 0.109 30,000 75,000 40,172 10,043 16,069 8,639
0.75 0.028 30,000 75,000 6,052 1,513 2,421 2,156
0.75 0.035 30,000 75,000 7,721 1,930 3,088 2,669
0.75 0.049 30,000 75,000 11,273 2,818 4,509 3,664
0.75 0.065 30,000 75,000 15,726 3,931 6,290 4,749
0.75 0.083 30,000 75,000 21,318 5,330 8,527 5,905
0.75 0.095 30,000 75,000 25,446 6,362 10,179 6,637
0.75 0.109 30,000 75,000 30,733 7,683 12,293 7,453
0.75 0.12 30,000 75,000 35,294 8,824 14,118 8,064
0.875 0.02 30,000 75,000 3,593 898 1,437 1,340
0.875 0.028 30,000 75,000 5,128 1,282 2,051 1,859
0.875 0.035 30,000 75,000 6,522 1,630 2,609 2,316L
0.875 0.049 30,000 75,000 9,459 2,365 3,784 3,172
0.875 0.065 30,000 75,000 13,087 3,272 5,235 4,126
0.875 0.083 30,000 75,000 17,560 4,390 7,024 5,152
0.875 0.095 30,000 75,000 20,803 5,201 8,321 5,807
0.875 0.109 30,000 75,000 24,886 6,221 9,954 6,543
0.875 0.12 30,000 75,000 28,346 7,087 11,339 7,100
1 0.028 30,000 75,000 4,449 1,112 1,780 1,633
1 0.035 30,000 75,000 5,645 1,411 2,258 2,027
1 0.049 30,000 75,000 8,149 2,037 3,259 2,796
1 0.065 30,000 75,000 11,207 2,802 4,483 3,647
1 0.083 30,000 75,000 14,928 3,732 5,971 4,567
1 0.095 30,000 75,000 17,593 4,398 7,037 5,159
1 0.109 30,000 75,000 20,908 5,227 8,363 5,827
1 0.12 30,000 75,000 23,684 5,921 9,474 6,336
1 0.134 30,000 75,000 27,459 6,865 10,984 6,963
1.25 0.035 30,000 75,000 4,449 1,112 1,780 1,633
1.25 0.049 30,000 75,000 6,380 1,595 2,552 2,260
1.25 0.065 30,000 75,000 8,705 2,176 3,482 2,958
1.25 0.083 30,000 75,000 11,485 2,871 4,594 3,719
1.25 0.095 30,000 75,000 13,443 3,361 5,377 4,213
1.25 0.109 30,000 75,000 15,843 3,961 6,337 4,776
1.25 0.12 30,000 75,000 17,822 4,455 7,129 5,207
1.25 0.134 30,000 75,000 20,468 5,117 8,187 5,742
1.5 0.035 30,000 75,000 3,671 918 1,469 1,367
1.5 0.049 30,000 75,000 5,243 1,311 2,097 1,896
1.5 0.065 30,000 75,000 7,117 1,779 2,847 2,487
1.5 0.083 30,000 75,000 9,333 2,333 3,733 3,136
1.5 0.095 30,000 75,000 10,878 2,719 4,351 3,559
1.5 0.109 30,000 75,000 12,754 3,188 5,101 4,043
1.5 0.12 30,000 75,000 14,286 3,571 5,714 4,416
1.5 0.134 30,000 75,000 16,315 4,079 6,526 4,881
1.5 0.148 30,000 75,000 18,439 4,610 7,375 5,336
1.75 0.035 30,000 75,000 3,125 781 1,250 1,176
1.75 0.049 30,000 75,000 3,864 966 1,546 1,434
1.75 0.065 30,000 75,000 6,019 1,505 2,407 2,146
1.75 0.083 30,000 75,000 7,860 1,965 3,144 2,711
1.75 0.095 30,000 75,000 9,135 2,284 3,654 3,080
1.75 0.109 30,000 75,000 10,672 2,668 4,213 3,504
1.75 0.12 30,000 75,000 11,921 2,980 4,768 3,832
1.75 0.134 30,000 75,000 13,563 3,391 5,425 4,242
1.75 0.148 30,000 75,000 15,268 3,817 6,107 4,645
1.75 0.165 30,000 75,000 17,430 4,357 6,972 5,124
2 0.035 30,000 75,000 2,720 680 1,088 1,032
2 0.049 30,000 75,000 3,864 966 1,546 1,434
2 0.065 30,000 75,000 5,214 1,303 2,086 1,887
2 0.083 30,000 75,000 6,788 1,697 2,715 2,387
2 0.095 30,000 75,000 7,873 1,968 3,149 2,715
2 0.109 30,000 75,000 9,175 2,294 3,670 3,092
2 0.12 30,000 75,000 10,227 2,557 4,091 3,384
2 0.134 30,000 75,000 11,605 2,901 4,642 3,751
2 0.148 30,000 75,000 13,028 3,257 5,211 4,111
2 0.165 30,000 75,000 14,820 3,705 5,928 4,542

ASME SA213 TP316, TP316L, TP316H, TP316Ti, TP316LN, SUS316, SUS316L, Stainless Steel Seamless Tube For Boiler
